51 bottle fully integrated dual zone commercial wine cellar designed for the display and refrigeration of beverages, with digital controls and LED lighting.
SUMMIT introduces fully integrated wine cellars for optimum storage and professional elegance. The VC60D is a dual zone wine cellar designed to store bottles under the ideal conditions. The door features a slightly tinted double pane tempered glass construction to protect your collection from UV light, with seamless stainless steel trim for a sleek, professional look. This unit includes a stylish stainless steel handle. The door swing is user reversible, offering more flexibility when positioning the unit. Inside, the VC60D features two distinct zones for storing reds and whites at the proper temperature. A digital thermostat offers easy temperature management, with an alarm that sounds when either interior temperature has drifted out of range. Five standard wooden shelves hold bottles in classic style, while the bottom shelf comes in a unique tilt design that lets you best display the labels for maximum effect. This unit can store up to 51 Bordeaux or 36 Burgundy style bottles, depending on exact bottle size and storage configuration. Recessed LED lighting provides an elegant view of the interior, with an optional setting of display or functional mode. Additional features include an open door alarm and Sabbath Mode setting for religious observance. The VC60D is auto defrost, with fan-forced cooling that ensures the interior temperature is evenly distributed and a condensation collection system that helps to maintain the correct level of humidity inside. With a stunning look and versatile design, the VC60D adds a great touch to any room. This unit is designed for fully integrated installation (cutout dimensions: 34 3/8" to 34 5/8 H x 21 5/8" W x 21 5/8" D). Lower zone is ideal for storing red and blush wine between 55 and 72ºF, while the upper compartment is better suited for cooler blushes and whites at 41 to 55ºF Meets UL-471 commercial standards Electronic controls ensure easy and intuitive temperature management, with a readout in Celsius or Fahrenheit Ensures evenly cooled interior for proper storage User-reversible door swing in double pane tempered glass for best protection from UV light Store bottles safely in classic style Unique design lets you stand bottles at an angle to display the label Sounds after door is left open for over a minute to best prevent accidents Can be set for showcase mode, remaining on until manually turned off, or functional model (turning on when the door is opened and off when it is closed) Alarm sounds off when unit's interior rises or falls out of the set range Optional setting lets you disable the lighting and alarms for 48 hours Designed for fully integrated installation (cutout dimensions: 34 3/8" to 34 5/8 H x 21 5/8" W x 21 5/8" D; see user manual for additional information about providing proper ventilation and spacing for this unit)) Proper humidity levels are maintained inside due to a specially designed condensation collection system Environmentally friendly design without ozone-damaging chemicals SPECIFICATIONSKEY FEATURES
DESCRIPTION
FEATURES
Height of Cabinet
34.88" (89 cm)
Width
23.25" (59 cm)
Depth
22.38" (57 cm)
Depth with Handle
25.13" (64 cm)
Depth with door at 90°
45.0" (114 cm)
Bottles
51 bottles
Defrost Type
Automatic
Door
Glass
Cabinet
Unfinished
US Electrical Safety
ETL
Canadian Electrical Safety
ETL-C
Amps
2.0
Voltage/Frequency
115 V AC/60 Hz
Weight
110.0 lbs. (50 kg)
Shipping Weight
115.0 lbs. (52 kg)
Parts & Labor Warranty
1 Year
Compressor Warranty
5 Years
UPC
761101031262
Number of Zones
2
Door Swing
RHD
Reversible
Yes
Shelf Type
Wood
Shelf Qty
6
Thermostat Type
Digital
Interior Light
Yes
Fan Type
Interior
Refrigerant Type
R134a
Refrigerant Amount
2.05 oz.
High Side PSI
270.0
Low Side PSI
105.0
Interior Height 1
10.0" (25 cm)
Interior Width 1
18.25" (46 cm)
Interior Depth 1
16.75" (43 cm)
Compressor Step Height
7.5" (19 cm)
Compressor Step Width
18.25" (46 cm)
Compressor Step Depth
4.5" (11 cm)
Interior Height 2
19.0" (48 cm)
Interior Width 2
18.25" (46 cm)
Interior Depth 2
15.0" (38 cm)
Sabbath Mode
Yes
