CellarPro 1/6 Ton Wine Cooling Unit (200 Cu.Ft. Capacity)

This CellarPro 1800QT-HE wine cooling unit delivers 1420 BTUH total / 1170 BTUH sensible capacity at 55F, making it one of the most efficient 1/6-ton cooling systems for small wine cellars and wine cabinets. Built with low-GWP R-290 refrigerant, high-efficiency EC fans and aluminum evaporator coils, this unit delivers quiet operation, strong airflow, and stable temperature and humidity control when installed in a properly constructed cellar.

Key Benefits:

• High-performance cooling: 1420 total / 1170 sensible BTUH @ 55F for optimal temperature and humidity management
• Low-GWP refrigerant: R-290 refrigerant with ultra-low GWP and zero ODP
• Quiet, efficient airflow: EC fan technology for reduced noise and improved airflow efficiency
• Longer coil life: Aluminum evaporator coils to help resist formicary corrosion and support longer service life
• Adjustable humidity control: Helps protect cork integrity and wine labels
• Compact design: Ideal for tight cabinet installs and small cellar environments

Performance Overview:

• Setpoint range: 51F-62F (cellar temperature)
• Designed to maintain ideal cellar conditions: Helps maintain humidity levels that support cork and label protection
• Best fit: Small residential wine cellars and wine cabinets requiring 1/6-ton cooling power

The 1800QT-HE cooling unit is an ideal upgrade path for customers searching for:

• A quieter wine cooling unit
• A more energy-efficient 1/6-ton wine cellar cooler
• A modern R-290 wine storage cooling solution

Installation Requirements:

For optimum performance and warranty coverage, the 1800QT-HE must be installed in a properly insulated, airtight wine cellar with a vapor barrier.

Recommended conditions and sizing assumptions:

• R-19 insulation or better
• No glass walls
• Vapor barrier installed on the warm side
• Ambient temperature up to 85F (sizing assumption)
• Access to fresh air from 40F to 95F (condenser air)

Ducting guidelines:

• Cold side cannot be ducted
• Hot side can be ducted only when using a CellarPro duct hood and auxiliary fan
• This model is engineered for indoor use only.

Technical Summary:

• Cooling capacity: 1420 total BTUH, 1170 sensible BTUH
• Nominal size: 1/6 ton wine cooling system
• Refrigerant: R-290 (ultra-low GWP)
• Fan type: EC (electronically commutated)
• Application: Wine cabinets, small wine cellars
• Certification: ETL-certified
