UBC Tayfun | Flash Beer Chiller, 3 Line Vertical with Manual Thermostat (V-400T3)

Original price $4,949.99 - Original price $4,949.99
Original price
$4,949.99 - $4,949.99
Current price $4,949.99

Estimated time to Ship:

2 Weeks

Flat rate shipping click HERE

An ideal choice for cooling beer, wine, or other beverages in settings with low capacity for conventional refrigeration. Similar in concept to a jockey box, this unit will cool up to 3 different beverages at once.


Flash chiller is an ideal choice for cooling draft beer, wine on tap, and other carbonated or non-carbonated beverages in places with limited possibilities for other types of refrigeration.

This particular model V-400T3 has 3 product lines, which means you can cool up to 3 different beverages at once, which is quite handy for small bars and restaurants. Quick cooling is achieved thanks to the 3 x 75’ stainless steel coils covered with ice-cold water.

Construction-wise, draft beer & wine keg cooling stations share some similarities with jockey boxes since they have an icebank with a stainless steel coil, which has to be covered with ice-cold water. The submerged agitator pump ensures quick and efficient cooling in any circumstances.


  • Capacity: from 1 to 3 product lines
  • Works with most beverages - alcoholic (beer or wine) and soft drinks (juice, seltzer, or water)
  • Cooling is achieved via running the product lines through 75’ stainless steel coils covered with ice-cold water
  • Icebank capacity: 115 lbs
  • Great for commercial use at bars, restaurants, and sports venues

Part Number V-400T3
Operating amperage, A 16.7
Water Tank volume, Gal 31
Outlet temperature, °F 38÷46
Water Pump capacity,GPH/PSIG 250/10
Ice Bank, lbs 115.6
Ice forming time (Tamb=75°F) 5.5 h
Dedicated Circuit, amp 30
Voltage/Hz 115/60
Compressor Power, hp 2 x 1/3hp
Number of Product Lines, Coils 3
Coil's Diameter Ø 8,0
Refrigerant R290
Dimensions WxDxH, in 26.1x26.5x38.8
